Brother TD-4520TN


Reliable desktop printer for labels and barcodes

The Brother TD-4520TN combines a compact format with professional performance. With 300 dpi resolution and support for both thermal transfer and direct thermal printing, it delivers crisp, durable labels up to 112 mm wide (usable 105.7 mm).

Offering print speeds of up to 127 mm/sec (5 ips), the TD-4520TN minimizes downtime and boosts efficiency. Connectivity includes USB 2.0, Ethernet LAN (10/100 Mbps), and RS-232 serial. The printer comes with Seagull BarTender UltraLite software included.

Suitable for producing labels on pallets, cartons, cardboard, glass, plastic, and metal, with full support for both 1D and 2D barcodes.

Why Choose Brother TD-4520TN

High-resolution printing icon
High-resolution printing
300 dpi guarantees sharp text, barcodes, and graphics for professional labels.

Versatile media icon
Wide media compatibility
Handles labels for pallets, cardboard, glass, plastics, and metals with ease.

Connectivity icon
Flexible connectivity
USB, Ethernet, RS-232; supports ZPL/ZPL2, EPL, and DPL languages.

Technical Specifications

Printing technology Thermal transfer / Direct thermal
Resolution 300 dpi (12 dots/mm)
Max print width 105.7 mm (usable up to 112 mm)
Max print speed 127 mm/sec (5 ips)
Max media width 112 mm
Max print length 11,430 mm (450 in)
Supported barcode types 1D: Code128, EAN-8/13, ITF-14, Code39, MSI, POSTNET, LOGMARS
2D: PDF417, DataMatrix, QR Code, Aztec, GS1 DataMatrix, etc.
Connectivity USB 2.0, USB host, Ethernet LAN, RS-232C serial
Memory 64 MB SDRAM, 128 MB flash
Software Seagull BarTender UltraLite included
Dimensions (W x D x H) 204 × 280 × 177.5 mm
Weight 2.5 kg
Operating temp./humidity 5 °C to 40 °C / 25–85% RH (non-condensing)
